AP / cv gate swap & switch / 14 HP

AP can be used to switch signals on and off or swap them between two destinations.

When a gate signal is applied to the GATE input IN B is connected to OUT A and IN A is connected to OUT B. When the gate signal is low, IN A goes to OUT A and IN B is connected to OUT B. You can also switch the signal manually using the latching switch in the middle of the module.

If nothing is connected to IN A, +5V are provided at the active output socket. This way you can use AP as a manual gate or as an alternating gate trigger for two targets.

key features

• Swap & Switch

• CV Gate activates Switch

• Manual Switch

• LED Indication

• Available in Intellijel Format

• Skiff friendly

specs & downloads

• width: 14 HP

• depth: 30 mm

• power: 19 mA @ +12V / 14 mA @ -12V
