ANTUMBRA

DVCA / dual vca

DVCA / dual vca

Regular price £84.99 GBP
Regular price Sale price £84.99 GBP
Sale Sold out
Options
Quantity

DVCA is a dual VCA based on the Mutable Instruments Veils. It features two separate voltage controlled amplifiers, both with a gain and a response curve potentiometer, that is variable from linear to exponential. The outputs are normaled, so when no patch cable is present on output 1, output 2 will contain both signals, allowing the module to be used as a mixer. Several DVCAs can be daisy-chained for voltage controlled mixer operation.

Technical Specs



CURRENT DRAW:

  • +12V:   17mA
  • -12V:   17mA
  • +5V:    0mA

DIMENSIONS:

  • WIDTH:   4HP
  • DEPTH:   20mm
